Sand Blasting Room
  • Sand Blasting Room
Sand Blasting Room

Sand Blasting Room

Product Features:

    Adopting compressed air as driving force and abrasives as media to blast the metal surface, a complete sand blast room should include room body and structure, recovery system, sand blast machine, dust removal system, lightening system, protections suits for workers, and compressed air (normally, the user will have compressed air at their site. ), etc.

Normally, a sand blast room is non-standard system which need to be designed independently according to the customer’s conditions and requirements. Such as workpiece details, whether you have a room, preferred recovery method, degree of automation, etc. Kaitai will provide one-stop blasting services for your most picky requirement.


Parameters for reference only

No.ModelSize of roomEfficient size of workingSpray gun quantity
1XDL-0606-M16000x6000x5000mm3000×3000×2500mm2
2XDL-0606-M26000x6000x6000mm3000×3000×3500mm2
3XDL-0806-M18000x6000x5000mm5000×3000×2500mm2
4XDL-0806-M28000×6000×6000mm5000×3000×3500mm2
5XDL-1006-M210000×6000×6000mm7000×3000×3500mm2
6XDL-1506-M215000×6000×6000mm12000×3000×3500mm2
7XDL-1508-M215000×8000×6000mm12000×5000×3500mm2
8XDL-1808-M218000×8000×6000mm15000×5000×3500mm4
9XDL-0806-M318000×10000×8000mm15000×7000×5500mm4
